ID |
Roller
O.D. |
Roller
Width |
Crown Radius |
Stud
Diameter |
Stud
Length |
M.E.T. |
Thread
Class
2A |
Hex Size |
|
A |
B |
K |
C |
D |
E |
F |
X |
CSFH-16-A |
0.500 |
0.375 |
7 |
0.190 |
0.625 |
1/4 |
10-32 |
1/8 |
CSFH-20-A |
0.625 |
0.4375 |
8 |
0.250 |
0.750 |
1/3 |
1/4-28 |
1/8 |
CSFH-22-A |
0.688 |
0.4375 |
8 |
0.250 |
0.750 |
1/3 |
1/4-28 |
1/8 |
CSFH-24-A |
0.750 |
0.500 |
10 |
0.375 |
0.875 |
3/8 |
3/8-24 |
3/16 |
CSFH-28-A |
0.875 |
0.500 |
10 |
0.375 |
0.875 |
3/8 |
3/8-24 |
3/16 |
CSFH-32-A |
1.000 |
0.625 |
12 |
0.4375 |
1.000 |
1/2 |
7/16-20 |
1/4 |
CSFH-36-A |
1.125 |
0.625 |
12 |
0.4375 |
1.000 |
1/2 |
7/16-20 |
1/4 |
CSFH-40-A |
1.250 |
0.750 |
14 |
0.500 |
1.250 |
5/8 |
1/2-20 |
1/4 |
CSFH-44-A |
1.375 |
0.750 |
14 |
0.500 |
1.250 |
5/8 |
1/2-20 |
1/4 |
CSFH-48-A |
1.500 |
0.875 |
20 |
0.625 |
1.500 |
3/4 |
5/8-18 |
5/16 |
CSFH-52-A |
1.625 |
0.875 |
20 |
0.625 |
1.500 |
3/4 |
5/8-18 |
5/16 |
CSFH-56-A |
1.750 |
1.000 |
20 |
0.750 |
1.750 |
7/8 |
3/4-16 |
5/16 |
CSFH-60-A |
1.875 |
1.000 |
20 |
0.750 |
1.750 |
7/8 |
3/4-16 |
5/16 |
CSFH-64-A |
2.000 |
1.250 |
24 |
0.875 |
2.000 |
1 |
7/8-14 |
7/16 |
CSFH-72-A |
2.250 |
1.250 |
24 |
0.875 |
2.000 |
1 |
7/8-14 |
7/16 |
CSFH-80-B |
2.500 |
1.500 |
30 |
1.000 |
2.250 |
1 1/8 |
1-14 |
1/2 |
CSFH-88-B |
2.750 |
1.500 |
30 |
1.000 |
2.250 |
1 1/8 |
1-14 |
1/2 |
CSFH-96-B |
3.000 |
1.750 |
30 |
1.250 |
2.500 |
1 1/4 |
1 1/4-12 |
3/4 |
CSFH-104-B |
3.250 |
1.750 |
30 |
1.250 |
2.500 |
1 1/4 |
1 1/4-12 |
3/4 |
CSFH-112-B |
3.500 |
2.000 |
30 |
1.375 |
2.750 |
1 3/8 |
1 3/8-12 |
3/4 |
CSFH-128-B |
4.000 |
2.250 |
30 |
1.500 |
3.500 |
1 1/2 |
1 1/2-12 |
3/4 |
